Summary:
YK-160 type swing pellet machine working principle: Make the stirred materials into granules of required size, or beat the lumpy materials into small granules.YK-160 type swinging granule machine adaptable materials: This machine is suitable for granu…
YK-160 type swing pellet machine working principle:
Make the stirred materials into granules of required size, or beat the lumpy materials into small granules.
YK-160 type swinging granule machine adaptable materials:
This machine is suitable for granulation in pharmaceutical, chemical, food, solid beverage and other industries.
Technical specifications:
|
model number |
Type A, Type B |
Type C (aggravated) |
|
production capacity（kg/h） |
100-200 |
150-300 |
|
Motor power（kw） |
2.2 |
3 |
|
Drum speed（r/min） |
65 |
65 |
|
Swing angle |
360° |
360° |
|
Drum diameter（mm） |
φ160 |
φ160 |
|
weights（kg） |
About 300 |
450 |
|
Overall dimensions（mm） |
1150×680×1150 |
1260×750×1150 |
CH-100 Trough Mixer Working Principle
CH series trough mixer is used for mixing powdery or wet materials, so that the main and auxiliary materials of different proportions are mixed evenly. This machine and material contact are made of stainless steel, pulp leaf and barrel gap is small, mixing without dead angle, mixing shaft is equipped with a sealing device at both ends, to prevent material diarrhoea, hopper using buttons pointing control, easy to discharging. Widely used in pharmaceutical, chemical, food and other industries.
CH-100 Tank Mixer Features
This machine is made of stainless steel at the contact place with materials, the gap between paddle and barrel is small, no dead angle for mixing, the two ends of stirring shaft are equipped with sealing device, which can prevent the material from falling out.
CH-100 Tank Mixer Application Scope
Widely used in pharmaceutical, chemical, food and other industries.
Technical specifications:
|
measure word（L） |
100 |
150 |
200 |
400 |
|
Motor power（kw） |
2.2 |
3 |
3 |
5.5 |
|
stirring speed（rpm） |
24 |
24 |
24 |
24 |
|
Pouring angle（×） |
105 |
105 |
105 |
105 |
|
weights（kg） |
350 |
500 |
650 |
1200 |
|
External Dimensions（mm） |
1400×500×1000 |
1600×600×1100 |
1800×700×1200 |
2000×820×1460 |
