The difference between two-dimensional mixer and three-dimensional mixer

    Two-dimensional mixer is in the X-axis and Y-axis movement in two directions, while the three-dimensional mixer is in the XYZ three-axis movement. Three-dimensional mixer efficiency and mixing degree is much higher than two-dimensional mixer. But if the enterprise mass production, material fluidity can be the case, two-dimensional mixer is more suitable, two-dimensional mixer is widely used in medicine, chemical industry, food, feed, pesticides and other industries, especially for large tonnage of a variety of solid-phase material mixing. The three-dimensional loading of the cylinder is driven by the active shaft, for the week after week of translational rotation and tumbling and other composite movements, prompting the material along the cylinder for the ring, radial and axial three-way composite movement, so as to achieve a variety of materials, mutual flow, diffusion, accumulation, adulteration, to achieve the purpose of uniform mixing, the machine is mainly used in the pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defence industries, as well as the various This machine is mainly used in pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defence industry and various scientific research units for high uniformity mixing of powder and granular materials.



       From the appearance of the structure, the two are very different, from the design point of view to compare, two-dimensional mixer can be designed to volume is relatively large, three-dimensional mixer design volume is small, the latter is more suitable for laboratory use, and the latter can be designed into a replaceable barrel type, easy to replace the mixing container, easy to clean up, construction of cross-infection, easier to meet the new version of the GMP standard.



       Two-dimensional mixer mixing barrel in the rotation at the same time and participate in the swing, so that the barrel of materials can be fully mixed, so that the machine has a rapid mixing, mixing volume, discharge convenient and so on. Three-dimensional mixer is the use of mechanical force and gravity, etc., will be two or more than two kinds of materials evenly mixed up, it is loaded with a large rate of up to 80% (ordinary mixer is only 40%), high efficiency, mixing time is short. And all parts of the cylinder for the arc transition, and after precision polishing treatment, to meet the GMP requirements, is currently an ideal product in the mixer.



      Both feeding methods can be manually feeding or vacuum feeding machine and screw feeding hopper feeding, which is the same place. Generally speaking, both materials are SUS304 stainless steel, special requirements can use SS316L stainless steel.
