Summary:
Product Features:◎ This machine adopts large-area sandwich heating method, with large heat transfer surface and high thermal efficiency.◎The machine is set with stirring, so that the material forms a continuous circulating state in the cylinder, whi…
Product Features:
◎ This machine adopts large-area sandwich heating method, with large heat transfer surface and high thermal efficiency.
◎The machine is set with stirring, so that the material forms a continuous circulating state in the cylinder, which further improves the uniformity of the material's heating.
◎The machine is set with stirring, so that slurry, paste, paste-like material drying can be carried out smoothly.
Scope of application:
◎ Pharmaceutical, food, chemical and other industries for the following materials drying:
◎ Suitable for slurry, paste and powder materials;
◎The heat-sensitive materials that require low-temperature drying;
◎Easy to oxidise, easy to explode, strong irritation, highly toxic materials;
◎Require the recovery of organic solvent materials.
|
Item |
Model |
|||||||
|
Name |
unit (of measure) |
ZB-500 |
ZB-750 |
ZB-1000 |
ZB-1500 |
ZB-2000 |
ZB-3000 |
ZB-5000 |
|
working volume |
L |
300 |
450 |
600 |
900 |
1200 |
1800 |
3000 |
|
Inner Cylinder Size |
㎜ |
φ600×1500 |
φ800×1500 |
φ800×2000 |
φ1000×2000 |
φ1000×2600 |
φ1200×2600 |
φ1400×3400 |
|
stirring speed |
rpm |
5-25 |
5-12 |
5 |
||||
|
Power consumption |
kw |
4 |
5.5 |
5.5 |
7.5 |
11 |
15 |
22 |
|
Jacket design pressure |
Mpa |
≤0.3 |
||||||
|
pressure inside the cylinder |
Mpa |
-0.09~-0.096 |
||||||
