Belt dryer

Category: Drying equipment series

Introduction: Working PrincipleBelt dryer distributes the materials to be processed on the conveyor belt through appropriate charging mechanism (such as star fabricator, oscillating belt, crusher or granulator), the conveyor belt passes through the passages compose…

+86-13906119320

Inquire

Product Info Pictures

Working Principle

Belt dryer distributes the materials to be processed on the conveyor belt through appropriate charging mechanism (such as star fabricator, oscillating belt, crusher or granulator), the conveyor belt passes through the passages composed of one or several heating units, each of which is equipped with air heating and circulating system, and each of which has one or several humidity exhausting systems, and when the conveyor belt passes through, the hot air passes through the materials on the conveyor belt from the top to the bottom or vice versa, so that the materials can be dried uniformly. When the conveyor belt passes through, the hot air passes through the materials on the conveyor belt from top to bottom or from bottom to top, so that the materials can be dried evenly.

Characteristics of equipment

Belt dryer (belt dryer) is commonly used continuous drying equipment, can be widely used in chemical industry, food, medicine, building materials, electronics and other industries, especially suitable for drying flakes, strips, granular materials with good air permeability, filter cake and paste materials, can also be shaped through the granulator or extruder for drying.

Scope of application

Seaweed, dehydrated vegetables, dates, granular feed, monosodium glutamate, chicken essence, coconut, organic colours, synthetic rubber, acrylic fibre, drugs, medicines, small wood products, plastic products, electronic components aging, curing and so on.

Technical parameters

model number		DW-1.2-8A	DW-1.2-10A		DW-1.6-8A	DW1.6-10A	DW-2.0-8A	DW-2.0-10A
Number of units		4	5		4	5	4	5
Dry section length(m)		8	10		8	10	8	10
Accessories Thickness(mm)		10~80
operating temperature(℃)		60~130
vapour pressure（Mpa）		0.2~0.8
Steam consumption（kg/h）		120~300	150~375		150~375	170~740	180~500	225~600
drying time(h)		0.2~1.2	0.25~1.5		0.2~1.2	0.25~1.5	0.2~1.2	0.25~1.5
drying strength（kg.h2o/㎡.h）		60~160	80~220		75~220	95~250	100~260	120~300
Total fan power（kw）		9.9	12.1	9.9		12.1	18.2	22.2
Total power of equipment（kw）		11.4	13.6	11.4		13.6	19.7	23.7
Overall dimensions（m）	A	1.2	1.2	1.6		1.6	2.0	2.0
	A1	2.28	2.28	2.68		2.68	3.2	3.2
	B	8.0	10.0	8.0		10.0	8.0	10.0
	B1	9.5	11.5	9.5		11.5	9.5	11.5
	C	2.5	2.5	2.5		2.5	2.6	2.6
