The powder material and binder are fully mixed into wet soft material in the cylindrical container by the mixing slurry at the bottom, and then cut into uniform wet particles by the side-mounted high-speed crushing paddle.

Equipment features

◎The machine adopts horizontal cylinder structure, reasonable structure.
◎Inflatable sealing drive shaft, can be switched to water when cleaning.
◎Fluidised granulation, the granules are nearly spherical with good flowability.
◎ 25% less binder than traditional process, shorter drying time.
Only 2 minutes of dry mixing and 1-4 minutes of granulation per batch, 4-5 times higher efficiency than traditional process.
It is completed in the same closed container, dry mixing - wet mixing - granulation, shortening the process.
The whole operation has strict safety protection measures.
It can be made into jacket type according to the user's requirement.

Technical Parameters

model number	A	B	C×D	E	F
50	320	950	1250×800	970	1650
150	420	1000	1350×800	1050	1750
200	500	1100	1650×940	1450	2050
250	500	1160	1650×940	1400	2260
300	550	1200	1700×1000	1400	2310
400	670	1300	1860×1100	1550	2410
600	750	1500	2000×1230	1750	2610



name	model number
	50	150	200	250	300	400	600
capacity L	50	150	200	250	300	400	600
throughput kg/batch	15	50	80	100	130	200	280
Mixing speed r.p.m	200/400	180/270	180/270	180/270	140/220	106/155	80/120
hybrid power kw	4/5.5	6.5/8	9/11	9/11	13/16	18.5/22	22/30
Cutting speed r.p.m	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000
Cutting power kw	1.3/1.8	2.4/3	4.5/5.5	4.5/5.5	4.5/5.5	6.5/8	9/11
Compressed air consumption m3/min	0.6	0.9	0.9	0.9	1.1	1.5	1.8
weights kg	500	800	1000	1300	1800	2200	2600
