KZL Series Granulator (Crusher)

Category: Granulating, mixing and crushing machine series

Introduction: Working Principle◎ Small heat generation when working. Less dust.◎ The stator screen is made of stainless steel, which is not easy to be damaged.◎ The clearance between crushing knife and screen is adjustable.◎ It can handle sticky, gummy, hot and…

+86-13906119320

Inquire

Product Info Pictures

Working Principle

◎ Small heat generation when working. Less dust.
◎ The stator screen is made of stainless steel, which is not easy to be damaged.
◎ The clearance between crushing knife and screen is adjustable.
◎ It can handle sticky, gummy, hot and wet materials.

Range of application

◎ Dry and wet granule homogenisation and granulation.
◎ Crushing and granulation of agglomerated materials.
◎ Granulation of wet materials.
◎ Grinding of heat-sensitive materials.

Technical Parameters

model number	unit (of measure)	100	180	300
Stator diameter	mm	100	180	300
Stator length	mm	98	178	298
production capacity	kg/h	20-150	100-1500	200-2500
power (output)	kw	1.1	1.5	3
number of revolutions per minute	rmp	180-1400	175-1400	200-1400
