Flash Vapour Dryer, Conical Twin Screw Spiral Mixer, Water Atomisation Dust Collector were shipped smoothly and successfully arrived at the guest unit!

Working principle:

       The hot air enters into the bottom of the drier tangentially and forms a strong rotating wind field driven by the stirrer. The paste material enters into the drier from the spiral feeder, under the strong action of the high-speed rotating stirring paddle, the material is dispersed by the action of impact, friction and shear, and the lump material is crushed rapidly, and fully contacted, heated and dried with the hot air. After dehydration, the dry material rises with the hot airflow, the grading ring will retain the large particles, the small particles are discharged from the centre of the ring out of the dryer, recovered by the cyclone separator and dust collector, and the non-dried or large materials are thrown to the wall by centrifugal force, and then fall to the bottom of the crushing and drying.



Performance characteristics:

       ◎ Organic combination of cyclone, fluidisation, spraying and crushing classification technology.

       Compact equipment, small size, high production efficiency, continuous production, realising ‘small equipment, large production’.

       The drying intensity is high, energy consumption is low and thermal efficiency is high.

       ◎Short residence time of materials, good quality of finished products, can be used for drying heat-sensitive materials.

       Negative pressure or micro-negative pressure operation, good airtightness, high efficiency, eliminating environmental pollution.



Adaptable materials:

      Organic matter: atrazine (pesticide insecticide), lauric acid septum, benzoic acid, benzoic acid, fungicidal dan, sodium oxalate, cellulose acetate, organic pigments, etc..

      Dyes: anthraquinone, black iron oxide, indigo pigment, butyric acid, titanium hydroxide, zinc sulphide, various azo dye intermediates.

      Inorganic substances: borax, calcium carbonate, hydroxide, copper sulphate, iron oxide, barium carbonate, antimony trioxide, various metal hydroxides, various heavy metal salts, synthetic cryolite and so on.

      Foodstuffs: soy protein, gelatinised starch, wine trough, wheat sugar, wheat starch, etc.

Product Description :

     By the spiral of the public and rotation of the material in the vertebral body to produce a composite movement, mainly produces four forms of movement:

1、Spiral rotation along the wall, so that the material along the cone wall for circular motion;

2, spiral rotation of the material from the bottom of the cone along the spiral rise;

3, the spiral of the public, the rotation of the composite movement so that part of the material is absorbed into the spiral cylindrical surface at the same time by the spiral rotation of the centrifugal force so that part of the material within the spiral cylindrical surface of the vertebral neck to discharge;

4, the rising material by its own gravity down. Four kinds of movement in the mixer to produce convection, shear, diffusion, so as to achieve the purpose of rapid and uniform mixing



Structure principle:

  Mixer by two asymmetric spiral piece of rapid rotation, the material upward lifting, the formation of two asymmetric along the cylinder arm from the bottom upward spiral material flow. Rotary arm driven by the spiral rotation, so that the material outside the spiral to varying degrees into the envelope of the stud. Part of the material is staggered to lift, another part of the material is thrown out of the stud, so as to achieve the full circumferential orientation of the material to constantly update the diffusion of the material is mentioned in the upper part of the two shares of the material in the middle of the cavity convergence, the formation of a general downward flow of material, supplemented by the bottom of the cavity, thus forming a convective cycle. Due to the complexity of the above movement, the material is evenly mixed in a short time, and the mixing degree is high.



Adaptation of materials:

       It is widely used in solid-solid mixing, solid-liquid mixing, liquid-liquid mixing in many industries, such as chemical industry, chemical fertiliser, oil field, oil refining, pesticide, veterinary medicine, paint, pigment, dyestuff, metallurgy, smelting, refractory materials, mining, building materials, electronics, plastics, feed, breeding, medicine, bioengineering, food, health products, ceramics, glass, and new materials, nuclear energy materials and so on.

Working Principle:

SC series water bath atomised dust collector is a new type of high efficient wet dust collector newly developed by our company, which integrates cyclone separation, humidification, fog catching, settling and gas separation, and can not only remove dust efficiently, but also effectively remove acidic and alkaline or poisonous gases in the dusty gas that can be dissolved in water. The treated exhaust gas reaches or is better than the national environmental protection standard; the dust collector has small running resistance, no need to clean up for life in the dust collection tower, stable and long-lasting dust removal function, and the investment is provincial, occupies a small area, and has low running cost. Widely used in foundry, metallurgy, chemical industry, pharmaceuticals and other fields of dust management and tail gas treatment.
